Pearls

Some key features to consider when assessing optic discs:

1. Asymmetry

2. Size

3. Rim contour

4. Color and cup

5. Blood vessels and heme

6. Peripapillary atrophy (alpha and beta zone)

7. RNFL

Mnemonic challenge - think of something better than: A Smart Retired Collie Barks at Peripheral Rodents. Let’s delve a little more into each of these features.

Asymmetry

• Less than 1% of non-glaucomatous nerves exhibit a difference in cup-to-disc ratio over 0.2 between nerves. If the right nerve has a C/D ratio of 0.7 and the left nerve has a C/D ratio of 0.5 without a clear etiology, think glaucoma until proven otherwise.

Size

• Average disc diameter is around 1.9 mm vertically and 1.8 mm horizontally. Vertical diameter <1.5 mm is considered smaller than average, and >2.2 mm is considered larger than average.

• Don’t be fooled by differences in disc diameter. Consider 1.2 million retinal ganglion cell axons exiting through scleral openings of 1.5 mm and 2.5 mm in diameter. A cup-to-disc ratio of 0.7 in a 2.5 mm nerve may not be pathologic, whereas a cup-to-disc ratio of 0.4 in a 1.5 mm nerve may actually be glaucomatous.

• It’s easy to measure disc diameter at the slit lamp. Adjust the height of the slit beam to match the vertical disc diameter, then multiply the measured diameter in mm by the reciprocal of the lens magnification factor, or the “correction factor” (for 90D, x1.3; 78D, x1.1; 66D, x1.0; 60D, x0.9)

• See below regarding the Disc Damage Likelihood Scale (DDLS) which includes disc size in the stratification of glaucoma risk.

Rim contour

• Localized loss the the neuroretinal rim usually starts at the inferior and superior temporal poles of the optic nerve head, which is why nerves with glaucomatous damage exhibit “vertical elongation” of the central cup

• The ISNT rule may help you catch early rim thinning at key locations - in normal eyes the thickness of the rim usually decreases in order from inferior, superior, nasal, to temporal. But as Captain Jack Sparrow would say, think of this rule as more of a guideline that will be disobeyed by some normal nerves once in a while.

• Focal notching or complete loss of neuroretinal rim should signifies a disc at higher risk for further glaucomatous damage.

Color and cup

• Glaucomatous nerves retain pink or orange color until very advanced stages of RNFL loss

• Watch out for nerves with pallor out of proportion to degree of cupping - in appropriate cases, non-glaucomatous etiologies should be explored (anterior ischemic optic neuropathy (AION), compressional lesion to the optic nerve (tumor or hemorrhage), secondary optic atrophies due to papilledema, inflammatory and infectious causes)

• The “laminar dot sign” can be seen in glaucomatous nerves as RNFL loss results in exposure of the lamina cribrosa within the scleral ring. However, this finding is present in a minority of normal eyes as well.

Blood vessels and heme

• Look for NVD in patients at risk for PDR

• Disc collaterals and tortuous veins can signify chronicity of IOP elevation

• Bayonetting of vessels can be notable in deep cups as vessels “dive” out of side down the sheer cliff and re-emerge at the bottom of the cup, appearing to skip a segment

• Baring of circumlinear vessels occurs when rim loss leaves vessels hanging like a rope suspended over a canyon; can also be a nonspecific finding

• Nasalization of the central retinal artery and central retinal vein is seen with advanced cupping

• Nerve fiber layer hemorrhages (Drance hemorrhages, splinter hemorrhages) on the disc can be highly variable and difficult to spot, even on a dilated exam. Disc photos are much better at picking these up. They occur in about a third of glaucoma patients and remain for weeks to months, followed by localized notching and visual field loss. Disc hemorrhages are more common in normal tension glaucoma and less common in advanced glaucoma (perhaps due to extensive RNFL loss). Disc hemes need to be taken seriously because they signify higher risk for functional vision loss. Very rarely PVDs, diabetes, BRVOs, anemia and blood thinners can also be responsible for optic nerve head hemorrhages.

Peripapillary atrophy

• PPA refers to the thinning and degeneration of the chorioretinal tissue just outside of the optic disc and the exposure of the retinal pigment epithelium (RPE), which gives the tissue a moth-eaten appearance.

• PPA is not the same as pigment or scleral crescents which can be seen in tilted or myopic discs; these tend to be very uniformly dark or white in color, while PPA is patchy and irregular.

• Zone α is a peripapillary crescent featuring RPE irregularities of hypo- and hyper-pigmented areas due to thinning of the chorioretinal tissue layer. Nasally, it is always separated from the disc by zone β or by the scleral ring if zone β is absent. Plenty of normal eyes have Zone α PPA so its presence doesn’t really mean anything.

• Zone β is immediately adjacent to the disc and features total RPE and choriocapillaris atrophy, revealing the underlying sclera and large choroidal vessels. Zone β is rare in normal eyes and more common in glaucomatous eyes.

• If all of that is too much to remember, you may be in luck - there are conflicting studies regarding the correlation between PPA and risk for glaucomatous progression.

RNFL

• You can actually see axons of the RNFL if you look carefully at the posterior pole - it can help to use the red-free filter to highlight the axons and areas of focal loss. A healthy nerve fiber layer appears as bright striations; focal loss of nerve fibers appear as dark bands; diffuse loss just looks like a sad, dark desert - usually in the superior and inferior poles relative to the nasal and temporal areas.
